Installation and Programming Manual
1-6
• 8 Hardwired Zones • Up to 8 partitions • Up to 99 User Codes • Auxiliary power output • Built-in siren driver • Utility output • 128 Event Log •“Follow Me”feature • Scheduling • Maintenance features
Programmable Outputs
Expansion Modules
Central Station
Monitoring
Remote Telephone
(remote control and
“Follow Me” capability)
Premises
Phones
Portable PC (for local downloading/uploading)
Keypads
LED + LCD
Hardwired Zones
Expansion Modules
Power Supply
Expansion Modules
Event Log
Expansion Modules
Voice Module
Printer Module
Wireless Receivers
Program Transfer
Modules
• Backlit keys / display • Tamper supervised • False code detection • Quick Arm key • 3 emergency key zones
• 8 zone capability • Auxiliary output power available
• Up to 8 modules possible • 12v.@ 1.5Amps • Built-in siren driver • Supports standby battery
• 512 or 999 Event Logging
Capabilities
• 8 or 16 wireless zone expanders • 868 / 433 MHz Frequency • Supervised tamper and jamming. • Wireless zones assignable to any
partition
• Can communicate with up to 16
X-10 receivers for light and appliance control
• Tamper supervised
X-10 Module
• 4 or 8 output capability • Follows system event • Relay or Transistor output
• Record and playback voice messages to
“Follow Me” phone numbers
• Up to 3 messages, total of 40 seconds • Messages can be assigned to a partition
and/or events
PREMISES
PHONES
TELCO LINE
4-WIRE BUS
4-WIRE BUS
4-WIRE BUS
Wireless Transmitters
• 868 / 433 MHz Frequency • Supervised for transmitter low battery
and tamper.
Remote PC (for remote downloading/uploading)
• 485 / 232 adapter • 485 / USB converter
4-WIRE BUS
• Can store any panel configuration for
easy copying to other systems
• Temporary use as required
