Installation and Programming Manual
3-92
N
N
o
o
t
t
e
e
s
s
f
f
o
o
r
r
U
U
L
L
I
I
n
n
s
s
t
t
a
a
l
l
l
l
a
a
t
t
i
i
o
o
n
n
s
s
Rechargeable Standby Battery
12 Volts 7 Amp-Hours (AH)
Auxiliary Power
12 Volts DC @ 280 mA, maximum
Bell
Use Ademco AB12M
Smoke Detectors
Use ESL/Sentrol models ES-449AT, ES-449C, ES-541CXT; Detection Systems: DS-DS284THC
Wiring
Use recognized energy-limited cable for connections of up to 100 VA when mounting initiating devices, indicating
devices, and supplementary devices. For units with no energy limitations, circuit connections should be enclosed in
conduit, metal cable, or wiring acceptable for Class 1 systems as defined by the National Electrical Code,
ANSI/NFPA 70-1996.
Configuration
To comply with full UL compatible installations:
The False Code feature should always be enabled.
Retard/Reset/Restart periods may not exceed 60 seconds for smoke detectors.
The feature Buzzer Bell should not be used.
The following features should not be used: Key Switch, N/O Termination, N/C Termination, Cross Zones,
Swinger limits, Auto Batch, Call Save (Disable feature), Ground pulse, Call back U/D, Low Battery and Low
Battery Reset report codes, Remote armed codes, Remote Download.
Warning
Shorting the terminals of S. Aux. Zone may cause permanent damage to the panel.
Accessories
The following accessories should not be used in UL installations: Wireless Expansion Modules, Keyswitches, X-10
Module, Digital Voice Module, Access Control Expansion Module, Printer Adapter Module, Program Transfer
Module.
