Rite‑Hite
®
Installation/Service/Owner's Manual FasTrax
®
XL
Publication: AMEN00316 2020-07-06 7
INSTALLATION
Preparation
NOTE: Refer to i-COMM 3 Installation/Service manual for
GUI/Touchscreen installation.
1. Check for electrical prints included in the parts or
control box. They supersede any prints in this manual.
2. Alternate measurements in brackets are in [metric].
3. Make sure you are working at the correct location and
have any required work permits.
4. Inspect installation site to make sure area is free
of overhead obstructions (sprinkler pipes, HVAC
systems, electrical supply lines, etc.) that might
interfere with the lifting of the header assembly during
installation.
5. Detour material handling equipment (fork lift trucks,
etc.) during the installation of the door.
6. Make sure that the electrician is ready to bring the
correct electrical power supply to the door control box.
7. Make sure that the electrical power can be shut off
without interfering with other plant operations.
8. Move the entire crate of the door components as
close to the door opening as possible.
9. If multiple doors are being installed, the control box
must be installed with the matching door unit. The
serial number for your door is on a label located on
the side of the control box and drive-side lower track
("Figure 74" on page 45).
10. To verify proper installation, use "Final Checklist" on
page 58.
11. Install Activation and Optional equipment after
verifying door operation.
Required Tools
Fork and scissors lift Hammer drill (cordless or electric)
Level (laser or hydro) 25ft [8m] tape measure
Ladder 6ft-8ft [2m-2.5m] Wire strippers (small-22 AWG)
[.64mm]
Utility knife 6ft [1.5m or 2m] carpenter's level
Electrical tape Square/straight edge
Hammer 5/16in [10mm] nut driver
Plumb bob "C" clamps
7/16in, 1/2in, 9/16in, 3/4in, 15/16in open end and/or socket wrench
11/16in x 12in [17mm x 305mm] drill bit for through bolting
Straight/Phillips screwdrivers (small 1/8in [3mm] spade)
Phillips bit and drill bits for drill
1/2in [13mm] masonry and/or drill bit for through bolting
Allen wrench set (1/8in, 3/16in, 5/32in, 1/4in, 2mm)
Stainless steel mounting hardware (supplied by others).
