1. TECHNICAL FEATURES ﺔﻴﻨﻔﻟا ﺺﺋﺎﺼﺨﻟا
1./2
ﺟرد ﻂﺒﺿ ةراﺮﺤﻟا ﺔ
50
÷320 ﺔﻳﻮﺌﻣ ﺔﺟرد
ﻞﻤﻌﻟا ةراﺮﺣ ﺔﺟرد ﻰﻟإ لﻮﺻﻮﻟا ﻦﻣز
< 20 ﺔﻘﻴﻗد
عﺎﻔﺗرﻻا ﻖﻤﻌﻟا ضﺮﻌﻟا ،دﺎﻌﺑﻷا ] ﻢﻠﻣ[
410×280×50 ﻢﻠﻣ
)16.1x11x2 ﺔﺻﻮﺑ(
-
470×50×490 ﻢﻠﻣ
)18.5x2x19.3 ﺔﺻﻮﺑ(
470×50×600 ﻢﻠﻣ
)18.5x2x23.6 ﺔﺻﻮﺑ(
696x175x700 ﻢﻠﻣ
)27.4x6.9x27.6
ﺔﺻﻮﺑ(
زﻮﻟا ن ] ﻢﺠﻠآ[
3 ماﺮﺟﻮﻠﻴآ)6.6
لﺎﻃرأ(
6 ماﺮﺟﻮﻠﻴآ)13.2
ًﻼ ﻃ ر(
8 ماﺮﺟﻮﻠﻴآ)17.6
ًﻼ ﻃ ر(
13 ماﺮﺟﻮﻠﻴآ)28.7
ًﻼ ﻃ ر(
18 ماﺮﺟﻮﻠﻴآ)39.7
ًﻼ ﻃ ر(
FACER
Nominal power [ W ] 1050 1050 1050 1050 900
Rotation speed [ RPM ] 109 109 73 67 22
Dimensions W D H [ mm ]
375×325×280 mm
(14.8x12.9x11 in)
-
440x450x380 mm
(17.3x17.7x15 in)
600×460×390 mm
(23.6x18.1x15.3 in)
931x615x220 mm
(36.6x24.2x8.7 in)
Weight [ kg ] 9 Kg (19.9 lb) 11 Kg (24.2 lb) 15 Kg (33.1 lb) 24 Kg (53 lb) 38 Kg (83.8 lb)
ﺔﻴﻜﻴﻟورﺪﻴﻬﻟا سوﺮﺘﻟا ﺔﺒﻠﻋ
ﻟا ﺔﻴﻤﺳﻻا ةرﺪﻘ ] تاو[
370 1100
ﻂﻐﻀﻟا قﺎﻄﻧ ] رﺎﺑ[
0
÷ 150 0 ÷ 120
ﻚﻴﻟورﺪﻴﻬﻟا ﺖﻳز
ﺔﺟوﺰﻠﻟا ﺔﺌﻓ46 وأ68 ISO 3448
ﻪﺑ ﻰﺻﻮﻤﻟا :TEXACO RANDO HDZ 46، ESSO UNIVIS N 46 SHELL TELLUS T 46
عﺎﻔﺗرﻻا ﻖﻤﻌﻟا ضﺮﻌﻟا ،دﺎﻌﺑﻷا ] ﻢﻠﻣ[
650x250x400 ﻢﻠﻣ)25.6x9.8x15.7 ﺔﺻﻮﺑ( -
نزﻮﻟا ] ﻢﺠﻠآ[
29 ماﺮﺟﻮﻠﻴآ)64 ًﻼ ﻃ ر( -
HEATING PLATE
Maximum absorbed power [ W ] 800 1800 2000 3000 3750
Temperature adjustment
50÷320°C
Time to reach working the
temperature
< 20 min.
Dimensions W D H [ mm ]
410×280×50 mm
(16.1x11x2 in)
-
470
×
50
×
490 mm
(18.5x2x19.3 in)
470×50×600 mm
(18.5x2x23.6 in)
696x175x700 mm
(27.4x6.9x27.6 in)
Weight [ kg ] 3 Kg (6.6 lb) 6 Kg (13.2 lb) 8 Kg (17.6 lb) 13 Kg (28.7 lb) 18 Kg (39.7 lb)
ﺔﻴﻜﻴﻟورﺪﻴﻬﻟا سوﺮﺘﻟا ﺔﺒﻠﻋ
ﺔﻴﻤﺳﻻا ةرﺪﻘﻟا ] تاو[
370 1100
ﻂﻐﻀﻟا قﺎﻄﻧ ] رﺎﺑ[
0
÷ 150 0 ÷ 120
ﻚﻴﻟورﺪﻴﻬﻟا ﺖﻳز
ﺔﺟوﺰﻠﻟا ﺔﺌﻓ46 وأ68 ISO 3448
ﻪﺑ ﻰﺻﻮﻤﻟا :TEXACO RANDO HDZ 46، ESSO UNIVIS N 46 SHELL TELLUS T 46
عﺎﻔﺗرﻻا ﻖﻤﻌﻟا ضﺮﻌﻟا ،دﺎﻌﺑﻷا ] ﻢﻠﻣ[
650x250x400 ﻢﻠﻣ)25.6x9.8x15.7 ﺔﺻﻮﺑ( -
نزﻮﻟا ] ﻢﺠﻠآ[
29 ماﺮﺟﻮﻠﻴآ)64 ًﻼ ﻃ ر( -
HYDRAULIC GEARCASE
Nominal power [ W ] 370 1100
Pressure range [ bar ]
0 ÷ 150 0 ÷ 120
Hydraulic oil
Viscosity class 46 or 68 ISO 3448
Recommended : TEXACO RANDO HDZ 46, ESSO UNIVIS N 46 SHELL TELLUS T 46
Dimensions W D H [ mm ] 650x250x400 mm (25.6x9.8x15.7 in) -
Weight [ kg ] 29 Kg (64 lb) -
ﻦﻴﺨﺴﺘﻟا حﻮﻟ ﺔﻣﺎﻋد/ةاﻮﺴﻤﻟا
عﺎﻔﺗرﻻا ﻖﻤﻌﻟا ضﺮﻌﻟا ،دﺎﻌﺑﻷا ] ﻢﻠﻣ[
340x440x230 ﻢﻠﻣ
)1.34x1.73x0.91
ﺔﺻﻮﺑ(
365x505x205 ﻢﻠﻣ
)14.4x19.9x8.1
ﺔﺻﻮﺑ(
-
690x560x290 ﻢﻠﻣ
)2.72x2.20x1.14
ﺔﺻﻮﺑ(
-
نزﻮﻟا ] ﻢﺠﻠآ[
6 ماﺮﺟﻮﻠﻴآ)13.2
ًﻼ ﻃ ر(
7.5 ماﺮﺟﻮﻠﻴآ)16.5
ًﻼ ﻃ ر(
9 ماﺮﺟﻮﻠﻴآ)19.9
ًﻼ ﻃ ر(
14 ماﺮﺟﻮﻠﻴآ)30.9
ًﻼ ﻃ ر(
-
FACER/HEATING PLATE SUPPORT
Dimensions W D H [ mm ]
340x440x230 mm
(1.34x1.73x0.91 in)
365x505x205 mm
(14.4x19.9x8.1 in)
-
690x560x290 mm
(2.72x2.20x1.14 in)
-
Weight [ kg ] 6 Kg (13.2 lb) 7,5 Kg (16.5 lb) 9 Kg (19.9 lb) 14 Kg (30.9 lb) -
