Ritmo BASIC 355 V0 - Specifications

1. TECHNICAL FEATURES ﺔﻴﻨﻔﻟا ﺺﺋﺎﺼﺨﻟا
1./1
ﺔﻣﺪﻘﻣ
BASIC ﻦﻴﻠﻴﺜﻴﻟﻮﺒﻟا ﻦﻣ ﺔﻋﻮﻨﺼﻤﻟا تﺎﺒﻴآﺮﺘﻟاو ﺮﻴﺳاﻮﻤﻠﻟ ﻊﻗﻮﻤﻟا ﻞﺧاد ﻲﺒآﺎﻨﺘﻟا مﺎﺤﻠﻟا تﺎﻨﻴآﺎﻣ ﻦﻣ ﺔﻠﺴﻠﺳ ﻲه)PE ( ﻦﻴﻠﻴﺑوﺮﺑ ﻲﻟﻮﺒﻟاو)PP ( ﻲﺘﻟا ىﺮﺧﻷا داﻮﻤﻟاو
ٍل ﺎ ﻋ ﻂﻐﺿ ﺖﺤﺗ نﻮﻜﺗ ﻲﺘﻟا ىﺮﺧﻷا ﻞﺋاﻮﺴﻟاو ﻩﺎﻴﻤﻟاو لﺎﻌﺘﺷﻼﻟ ﻞﺑﺎﻘﻟا زﺎﻐﻟا ﻞﻘﻨﻟ ﺔﺼﺼﺨﻤﻟا ةراﺮﺤﻟﺎﺑ نﺪﻠﺗ.
ﻣ ﻊﻴﻤﺟ تﺎﻨﻴآﺎ
BASIC ﺎﻬﻧﺎﻜﻣﺈﺑPE 100 جودﺰﻤﻟا ﻂﻐﻀﻟا ﺔﻘﻳﺮﻃ ماﺪﺨﺘﺳﺎﺑ.
ﺔﻣﺪﺨﺘﺴﻤﻟا ﺢﺋاﻮﻠﻟاو ﻦﻴﻧاﻮﻘﻠﻟ ﺎًﻘﻓو ،ﻦﻳﺪﻤﺘﻌﻤﻟاو ةﺮﻬﻤﻟا داﺮﻓﻷا ﻰﻠﻋ اًرﻮﺼﻘﻣ نﻮﻜﻳ ﺔﻠﺛﺎﻤﻤﻟا تﺎﻨﻴآﺎﻤﻟا ماﺪﺨﺘﺳا نﺄﺑ كﺮآﺬﻧ ﻦﺤﻧو.
INTRODUCTION
BASIC is a line of on-site butt welding machines for pipes and fittings in Polyethylene (PE), Polypropylene (PP), and other
thermoplastic materials intended for the transport of combustible gas, water, and other fluids under high pressure.
All BASIC machines can weld PE 100 with the Dual Pressure method.
We remind you that the use of such machines is limited to authorized skilled and certified personnel, in accordance with the
Legislation and Regulations in force.
SPECIFICATIONS تﺎﻔﺻاﻮﻤﻟا
ﺺﺋﺎﺼﺨﻟا
BASIC 160 V1 BASIC 200 V0 BASIC 250 V1 BASIC 315 V1 BASIC 355 V0
220V 220V 220V 220V 220V
ﺮﻄﻘﻟا ىﺪﻣ ] ﻢﻠﻣ[
∅ 40÷160 ∅ 63÷200 ∅ 75÷250 ∅ 90÷315 ∅ 125÷355
مﺎﺤﻠﻟ ﺔﻠﺑﺎﻗ داﻮﻣ HDPE: PE 80 (MRS 8 (وPE 100 (MRS 10( وPP ﺘﻟا ىﺮﺧﻷا داﻮﻤﻟاوةراﺮﺤﻟﺎﺑ نﺪﻠﺗ ﻲ
ﺔﻄﻴﺤﻤﻟا ةراﺮﺤﻟا ﺔﺟرد قﺎﻄﻧ ] ﺔﻳﻮﺌﻣ ﺔﺟرد[ ﻦﻣ-5 ﻰﻟإ+40 )PE 100 : ﻦﻣ0 ﻰﻟإ+40(
ﺔﻗﺎﻄﻟا داﺪﻣإ
220 بوﺎﻨﺘﻣ رﺎﻴﺗ ﻂﻟﻮﻓ60 ﺰﺗﺮه
ﺔﺼﺘﻤﻤﻟا ﺔﻗﺎﻄﻠﻟ ﻰﺼﻗﻷا ﺪﺤﻟا ] تاو[
2220 3220 3420 4420 5750
لﺰﻌﻟا ﺔﺌﻓ
1 :ﺔﻳﺎﻤﺤﻟا ﻞﺻﻮﻣ
ءﺎﺿﻮﻀﻟا ىﻮﺘﺴﻣ ] ﻞﺒﺴﻳد)ﺒﻣأﺮﻴ[ (
L
eq
=79.2
نزﻮﻟا- ﺺﺋﺎﺼﺨﻟا ﻊﻴﻤﺟ ﻊﻣ ﺔﻨﻴآﺎﻤﻟا]ﻢﺠﻠآ[
70 ماﺮﺟﻮﻠﻴآ)155
ًﻼ ﻃ ر(
93 ماﺮﺟﻮﻠﻴآ)205
لﺎﻃرأ(
124 ماﺮﺟﻮﻠﻴآ
)273.3 ًﻼ ﻃ ر(
166 ماﺮﺟﻮﻠﻴآ)366
ﻞﻃر(
-
FEATURES
BASIC 160 V1 BASIC 200 V0 BASIC 250 V1 BASIC 315 V1 BASIC 355 V0
220V 220V 220V 220V 220V
Diameters range [ mm ]
∅ 40÷160 ∅ 63÷200 ∅ 75÷250 ∅ 90÷315 ∅ 125÷355
Weldable materials HDPE: PE 80 (MRS 8) and PE 100 (MRS 10), PP and other thermoplastics materials
Ambient temperature range [ ° C ] from -5 to +40 (PE 100: from 0 to +40)
Power supply 220VAC 60Hz
Maximum absorbed power [ W ] 2220 3220 3420 4420 5750
Isolation class 1: protection conductor
Noise level [ dB (A) ] L
eq
=79.2
Weight - machine with all features [kg] 70 Kg (155lb) 93 Kg (205 lb) 124 Kg (273.3 lb) 166 Kg (366 lb) -
ﻪﻴﺳﺎﺸﻟا
ﻲﻟﺎﻤﺟﻹا ﻊﻓﺪﻟا ﻢﺴﻗ ]ﻢﺳ
2
[
1,947 3,156 5,890 6,680 14,130
عﺎﻔﺗرﻻا ﻖﻤﻌﻟا ضﺮﻌﻟا ،دﺎﻌﺑﻷا ] ﻢﻠﻣ[
606x365x375 ﻢﻠﻣ
)23.9x14.4x14.8
ﺔﺻﻮﺑ(
685
×460×420 ﻢﻠﻣ
)27x18.2x16.5 ﺔﺻﻮﺑ(
850x470x400 ﻢﻠﻣ
)33.5x18.5x15.7
ﺔﺻﻮﺑ(
981x586x520 ﻢﻠﻣ
)38.6x23x20.5 ﺻﻮﺑﺔ(
1077x510x715 ﻢﻠﻣ
)42.4x20x28 ﺔﺻﻮﺑ(
نزﻮﻟا ] ﻢﺠﻠآ[
21 ماﺮﺟﻮﻠﻴآ)46.3
ﺎًﻠﻃر(
39 ماﺮﺟﻮﻠﻴآ)86
ًﻼ ﻃ ر(
63 ماﺮﺟﻮﻠﻴآ)138.9
ًﻼ ﻃ ر(
86 ماﺮﺟﻮﻠﻴآ)189.6
ًﻼ ﻃ ر(
100 ماﺮﺟﻮﻠﻴآ
)220.5 ًﻼ ﻃ ر(
CHASSIS
Overall thrust section [ cm
2
] 1,947 3,156 5,890 6,680 14,130
Dimensions W D H [ mm ]
606x365x375 mm
(23.9x14.4x14.8 in)
685
×460×420 mm
(27x18.2x16.5 in)
850x470x400 mm
(33.5x18.5x15.7 in)
981x586x520 mm
(38.6x23x20.5 in)
1077x510x715 mm
(42.4x20x28 in)
Weight [ kg ] 21 Kg (46.3 lb) 39 Kg (86 lb) 63 Kg (138.9) 86 Kg (189.6 lb) 100 Kg (220.5 lb)
ةاﻮﺴﻤﻟا
ﺔﻴﻤﺳﻻا ةرﺪﻘﻟا ] تاو[
1050 1050 1050 1050 900
ناروﺪﻟا ﺔﻋﺮﺳ ] ﺔﻘﻴﻗﺪﻟا ﻲﻓ ةرود[
109 109 73 67 22
عﺎﻔﺗرﻻا ﻖﻤﻌﻟا ضﺮﻌﻟا ،دﺎﻌﺑﻷا ] ﻢﻠﻣ[
375×325×280 ﻢﻠﻣ
)14.8x12.9x11 ﺔﺻﻮﺑ(
-
440x450x380 ﻢﻠﻣ
)17.3x17.7x15 ﺔﺻﻮﺑ(
600
×460×390 ﻢﻠﻣ
)23.6x18.1x15.3
ﺻﻮﺑﺔ(
931x615x220 ﻢﻠﻣ
)36.6x24.2x8.7
ﺔﺻﻮﺑ(
نزﻮﻟا ] ﻢﺠﻠآ[
9 ﻢﺠﻠآ)19.9 ًﻼ ﻃ ر(
11 ماﺮﺟﻮﻠﻴآ)24.2
ًﻼ ﻃ ر(
15 ماﺮﺟﻮﻠﻴآ)33.1
ًﻼ ﻃ ر(
24 ماﺮﺟﻮﻠﻴآ)53
ًﻼ ﻃ ر(
38 ماﺮﺟﻮﻠﻴآ)83.8
ًﻼ ﻃ ر(
ﻦﻴﺨﺴﺘﻟا حﻮﻟ
ﺔﺼﺘﻤﻤﻟا ﺔﻗﺎﻄﻠﻟ ﻰﺼﻗﻷا ﺪﺤﻟا ] تاو[
800 1800 2000 3000 3750
