Ritmo BASIC 355 V0 - Page 79

9. WELDING PARAMETERS مﺎﺤﻠﻟا تﺎﻤﻠﻌﻣ
9./7
ﺔﻌﺑاﺮﻟا ﺔﻠﺣﺮﻤﻟا :مﺎﺤﻠﻟا ﻂﻐﺿ ﻰﻟإ لﻮﺻﻮﻟا
t
4
= 10 ﺔﻴﻧﺎﺛ مﺎﺤﻠﻟا ﻂﻐﺿ ﻰﻟإ لﻮﺻﻮﻟا ﺖﻗ
و
PHASE 4: Reach of welding pressure
t
4
= 10 sec
Time to reach the welding pressure
ﺔﺴﻣﺎﺨﻟا ﺔﻠﺣﺮﻤﻟا : مﺎﺤﻠﻟا ﺖﻗو1
P
5
= P
1
]رﺎﺑ[
مﺎﺤﻠﻟا ﻂﻐ
ﺿ
5
t
5
= 10 ﺔﻴﻧﺎﺛ
مﺎﺤﻠﻟا ﺖﻗ
و
5
PHASE 5: Welding TIME 1
P
5
= P
1
[bar]
Welding pressure 5
t
5
= 10sec
Welding time 5
ﺔﺳدﺎﺴﻟا ﺔﻠﺣﺮﻤﻟا : مﺎﺤﻠﻟا ﺖﻗو2
مﺎﺤﻠﻟا ﻂﻐ
ﺿ
6
t
6
= 3 + s ]ﺔﻘﻴﻗد[ مﺎﺤﻠﻟا ﺖﻗ
و
6
PHASE 6: Welding TIME 2
Welding pressure 6
t
6
= 3 + s [min]
Welding time 6
ﺔﻌﺑﺎﺴﻟا ﺔﻠﺣﺮﻤﻟا :ﺪﻳﺮﺒﺘﻟا
t
7
= 1,5 × s ]ﺔﻘﻴﻗد[ ﺪﻳﺮﺒﺘﻠﻟ ﺖﻗو ﻰﻧدأ
PHASE 7: Cooling
t
7
= 1,5 × s [min]
Minimum cooling time
P
1
3
P
6
] =رﺎﺑ[
P
1
3
P
6
= [bar]
