用户手册(Manual)
14
2. Installation parameters of cabinet
19’ dimention of mounting angle
A=Front CabinetAperture
B = Hole-to-Hole pacing
451mm -1/+1.6mm
465mm [18.307”] nominal
19’ dimention of mounting hole
square
