6. Adjustment of the mounting angle
In order to meet the installation requirements of different depth 19 equipment, mounting
Angle of the cabinet can be moved forward and backward，The limit distance of mounting angle
is shown in page 13;
Note: the adjustment distance of the mounting angle gauge is 25 mm.
600w cabinet
600w cabinet
800w cabinet
