10．Installation of Base plate(optional accessory)
1. Base plate shall be selected according to the width and depth of the cabinet ,each pair
base plate have 4 diameter 110 cable holes ,The following is the standard material number that
can be ordered directly.
material
number
English description
Chinese description
Corresponding
cabinet size
W(mm)*D(mm)
1194494
SR IT base plate W600D600
SR IT 底板 W600D600
600*600
1194495
SR IT base plate W600D800
SR IT 底板 W600D800
600*800
1194496
SR IT base plate W600D1000
SR IT 底板 W600D1000
600*1000
1194497
SR IT base plate W600D1100
SR IT 底板 W600D1100
600*1100
1194498
SR IT base plate W600D1200
SR IT 底板 W600D1200
600*1200
1194499
SR IT base plate W800D600
SR IT 底板 W800D600
800*600
1194500
SR IT base plate W800D800
SR IT 底板 W800D800
800*800
1194501
SR IT base plate W800D1000
SR IT 底板 W800D1000
800*1000
1194502
SR IT base plate W800D1100
SR IT 底板 W800D1100
800*1100
1194503
SR IT base plate W800D1200
SR IT 底板 W800D1200
800*1200
2.Dimention of base plate is shown in the table below.
material
number
Dimention
WidthA(mm)*Depth B(mm)
1194494
512*512
1194495
512*712
1194496
512*912
1194497
512*1012
1194498
512*1112
1194499
712*512
1194500
712*712
1194501
712*912
1194502
712*1012
1194503
712*1112
