Riva RC1202HD - Electrical Characteristics; Environment Condition; Mechanical Condition

25
www.rivatech.de
Electrical Characteristics
Power Source
DC 12V / PoE IEEE802.3af compliant(Class 0)
Video Output
1 Vp-p, 75Ω, Composite
Audio Input
Linein, 1.43Vp-p(Min 1.35Vp-p, max 1.49 Vp-p),
39 KΩ
Audio Output
Lineout, 46mW Power, 16 Ω
D/I
Max 50mA@5VDC, 1.5V threshold
D/O
Max 50mA@24VDC
On-state resistance: 50 Ω (max continuous)
Environment Condition
Operating Temperature
DC12V : 0˚C ~ 50˚C (32˚F ~ 122˚F)
PoE : 0˚C ~ 50 ˚C (32˚F ~ 122˚F)
Operating Humidity
Up to 85% RH
Mechanical Condition
Material
Aluminum Die Casting
Color
White
Dimension
71(W) x 64(H) x 140(D) mm
Weight (Approx)
500g
