5. Reset Button
Use the reset button to restart or reset the camera back to factory default settings.
Refer to the section “Fehler! Verweisquelle konnte nicht gefunden werden.” for more
pecific information.
6. RS-485 Termination Switch (120ohm)
Select ON or OFF for RS-485 termination register. The default is off.
7. Network Port
Use the RJ45 LAN connector for connecting the camera to network or supplying PoE
power.
8. USB 2.0 Port
Plug an USB flash drive or wireless LAN device.
9. SD Card Slot
Support memory cards up to 32GB.
10. Auto Iris Lens Connector
The 4-pin connector for an DDC drive auto iris lens.
11. Light Sensor
The light sensor is used to detect the level of ambient light detect intensity of light. The
sensor should not be blocked by cable or any other objects.
