Riva RTC series - Technical Specifications

RTC Series RTC Installation Guide
01A.04 17
APPENDIX (A): SPECIFICATIONS
Summary
Camera Module
Camera
Module
Focal
Plane
Array
17 ㎛ Next Generation Mirobolometer Technology
Effective
Pixels
320(H)x240(V)
Scanning
system
Progressive Scan
Spectral
Reponse
8~14 ㎛
Lens
(optional)
7.5mm, F1.4 (42.1 Degree FoV)
16.7mm, F1.2 (18.7 Degree FoV)
25mm, F1.2 (12.4 Degree FoV)
35mm, F1.2 (8,9 Degree FoV)
50mm, F1.2 (6.2 Degree FOV)
Other Lenses available upon request
NEDT
Less than 50mK
Electrical Characteristics
Analog Video Output
1Vp-p, 75Ω
Audio Input
Linein, 1.43Vp-p(Min 1.35Vp-p, max 1.49 Vp-p), 39
KΩ
Audio Output
Lineout, 46mW Power, 16 Ω
Sensor(D/I)
Max 50mA@5VDC, TTL level 1.5V threshold
Alarm(D/O)
Max 50mA@24VDC
On-state resistance: 50 Ω (max continuous)
Power Source
DC 12V / PoE IEEE802.3af(class 0)
Power Consumption
(Approx.)
6~8W(DC 12V)
Video
Compression Format
H.264, MPEG-4, MJPEG Selectable per Stream
Number of Streams
Dual Stream, Configurable
Resolution
Sensor is 320x240, Image can be scaled from QCIF to
D1
Compression FPS
9Hz or 30Hz Models Available
Motion Detection
Supported (DSP)
Burnt-in Text (Digital)
Supported (DSP)
Output
1 Loop Out (BNC connector)
Audio
