Riva RTC series - Device Connections Overview

RTC Series RTC Installation Guide
01A.04 8
4. CONNECTIONS
The device is polarity sensitive. Incorrect power connection may
cause the device to malfunction or damage the equipment.
Caution
!
DC Jack Adaptor
Cabl
LAN Cable
Analog Video Out
ETHERNET
Micro SD
RESET
LOOP OUT
DC 12V
RS-485
DO DI AUDIO
_
+ C 1 C 1 Out In
Intelligent Thermal Camera
Power Adaptor
