APPENDIX [E]: CAMERA HOUSING
The housing protects the surveillance device from material weathering,
intentional vandalizing, and miscellaneous environmental impacts. This
weatherproof IP66 housing has heater and fan attached inside, which are
controlled by the sensor.
Housing Overview
Models
ODE-1000T-PoE, ODE-1000T-230
Material
Aluminum die casting
Color
Ivory
Paint
Powder coating
Size (mm)
160(W) x 165(H) x 425(D)mm
Weight
5Kg
Heater/Fan Control
Heater: 0 (ON) / 10 (OFF)
Fan: 35℃ (ON) / 25℃ (OFF)
Operating
Temperature.
ODE-1000T-PoE: -20 ~ 50℃
ODE-1000T-230: -40 ~ 50℃
Input power
ODE-1000T-PoE: PoE+, 50/60Hz
ODE-1000T-230: AC90V ~ 230V, 50/60Hz
Protection
IP66
Positioning of Camera Mount by Lens
LENS
Mount Position
Bracket Position
7.5mm
A
1
16.7mm
A
1
25mm
B
1
35mm
A
2
50mm
C
2
