Rivacold ST Series - Page 151

ST-SP Pag. 151 Rev 02 05/13
ST Range
Drawing 6
HBP MBP LBP
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Cond.Unit Evap. Cond.Unit Evap. Cond.Unit Evap.
STH003__
STH006__
10
10
6
6
44.3
45.7
6.1
7.2
STM003__
STM006__
10
10
6
6
45.3
46.7
6.1
7.2
STL003__
STL006__
10
12
6
6
53.8
54.6
6.1
7.2
Drawing 7
HBP MBP LBP
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Cond.Unit Evap. Cond.Unit Evap. Cond.Unit Evap.
STH009__
STH016__
12
12
6
6
53.5
57
10.7
12.5
STM009__
STM012__
STM016__
12
12
12
6
6
6
47
55
57
10.7
10.7
12.5
STL009__ 12 6 68.6 10.7
Drawing 8
LBP
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Cond.Unit Evap.
STL012__ 12 10 65 10.7
188
1106
433
995
øest.20
205
min 150
D
S
656
188
433
min150
205
545
øest. 20
D
S
188
1106
433
995
øest.20
205
min 150
D
S
