Rivacold ST Series - Page 152

ST-SP Pag. 152 Rev 02 05/13
Drawing 9
HBP MBP LBP
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Cond.Unit Evap. Cond.Unit Evap. Cond.Unit Evap.
STH022__ 16 10 62.3 17.7 STM022__ 16 10 63 19 STL016__ 16 10 74 19
Drawing 10
HBP MBP LBP
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Cond.Unit Evap. Cond.Unit Evap. Cond.Unit Evap.
STH034__
_
16 10 84.8 25.2 STM34__ 16 10 85 27 STL020__ 16 10 70 30
Drawing 11
HBP MBP LBP
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Cond.Unit Evap. Cond.Unit Evap. Cond.Unit Evap.
STH054__ 16 10 90.8 28.2
STM040
STM054
16
18
10
10
87
89
30
30
STL024__
STL034__
16
18
10
10
88
100
27
30
Ø
Ø
Ø
