request the same grade of replacment as the original, you will not need to re-bias the amplifier
(provided
the bias was not adjusted from the original Rivera factory setting).
Footswitch Extension Cable: An optional 10-meter-long, 8-pin DIN male-to-female extension
cable is
available. Coupling the extension cable with the FS-7 footswitch’s 5-meter-long cable provides for
a 15-
meter total length. Up to two extensions may be used end to end between the Sedona and the FS-7.
S P E C I F I C AT I O N S
Speaker Output Impedance: 8 ohms
Direct Box Output Impedance: 600 ohms
Preamp Tubes: Two 12AX7A
Output Tubes: Two EL-34
Output Power: 55 Watts RMS into 8 ohms
Mains Operating Voltage: 115 Volts AC 50/60 Hz (North America), or 230VAC 50 Hz
(CE/Nemko model), 250 VAC 50 Hz (UK, Australia, New Zealand, and South Africa) or 100 VAC
50/60 Hz (Japan Only)
Speaker system: 12" Celestion G12T-75 8-ohm, high-power dome tweeter
Speaker System power handling: 75 Watts RMS
Crossover Network: 12 dB/octave air-core inductor
Crossover frequency: 4kHz
Reverb Type: Accutronics Spring
Height: 18"
Width: 20.75"
Depth: 12"
Weight: 49 lbs (estimate)
Cabinet Thickness: 3/4"
Baffle board: 3/4" Plywood
Covering: Nubtex
Cleaning of vinyl covering: Moist cloth, dishwashing liquid
Care of Grille cloth: Remove frame, use compressed air to blow out dust.
Because we strive to build the highest-quality product, we reserve the right to change specifications
of our products without prior notice.
Rivera Amplification
508 S. Varney, Burbank, CA 91502 USA
Phone: (818) 767-4600 • Fax: (818) 394-2097
Email: support@rivera.com • http://www.rivera.com
