The closer the “A” is to the edge, the more likely the
Reject.
A symbol is “Acceptable” until any calculated bar width
deviation exceeds 100% of the tolerance for the
symbology decoded; for example:
Acceptable
-100% Tol. +100%
------RRARR+++++
Warning
-100% Tol. +100%
--------++RRRARR
Rejected
-100% Tol. +100%
--------+++++++R
“A” is out of tolerance and off the screen.
Note:
Could also be on negative side (See Table 9-A for
visual display of deviations)
