Operator’s Guide Inspector D4000™ Auto Optic
002-5564 RJS, Minneapolis, MN
Press Select to display the next screen:
Defects 07% A
Appl. Compl. A
The Defects value is displayed on the top row.
The Application Compliance grade is displayed on the
bottom row (A or F). If any symbology parameter such
as mod check, ratio, character type or inter-character
gap is analyzed and found in error, an “F” grade will be
given, and this will affect the overall symbol grade (per
the ISO/ANSI specification).
Press Select to display the Decoded Symbol Data:
*1234ABCDEF456*
The decoded symbol data displays.
(If more than 16 characters are present, those
characters will wrap to the next row of the display. If
more than 32 characters are present, press Select to
scroll through the remaining data)
Code 128 is displayed in sixteen columns of two alpha-
numerics each. Each column represents a decoded
Code 128 symbol character. Two 16 column fields are
used to represent a 32 character decode. See Appendix
E for details regarding display of Code 128 on Data
Analysis Screens.
