ISO/ANSI Analysis Screens
Press Select again to display the first technical Data
Analysis screen.
Ref Decode A
Decodable 78% A
This screen shows the grades for the symbol’s reference
Decode and Decodability.
Press Select to display the next screen:
Sym. Cntr 84% A
Rmin/Rmax 01% A
This screen shows the ISO/ANSI Symbol Contrast on
the top row and Rmin/Rmax calculation on the bottom
row.
Press Select to display the next screen:
Ecmin 66% A
MODulation 78% A
This screen shows the symbol’s ISO/ANSI Minimum
Edge Contrast value on the top row and the Modulation
value on the bottom row.
