RJS Inspector D4000 - Text Analysis Output

Operator’s Guide Appendix I
002-5564 RJS, Minneapolis, MN
58
Revision A.06
02-Scan Average Analysis
Code 3of9
*1234*
Scan Profile Analysis
Reference Decode..............A
Decodability............76%...A
Symbol Contrast.........93%...A
Refl (Min)/Refl (Max....07%...A
Edge Contrast (Min).....57%...A
MODulation..............61%...B
Defects.................05%...A
Application Compliance........A
Overall Symbol Grade
B/10/660 3.0/10/660
Traditional Analysis
Acceptable
-100% Tol. +100%
--------++AR++++
Print Contrast signal..92% PASS
Required PCS...........75%
Element Refl. (Max)....92% PASS
Reflectance (Min)......07% PASS
Pass/Fail Analysis
Passing Grade Selected.......D
Final Results..........*PASS*
Text Analysis
Grade B/3.0 using a
10 mil aperture and
660nm wavelength
(red)
of light
See Appendix K
(Bar
code defin
i
tions)
See Appendix K
(Bar c
ode defin
i
tions)
