3 • 72-2102-07 Beacon 200 Operator’s Manual
Specifications
Table 1 lists specifications for the 72-2102-07 Beacon 200.
WARNING: When using the Beacon 200, you must follow the
instructions and warnings in this manual to assure
proper and safe operation of the Beacon 200 and to
minimize the risk of personal injury. Be sure to maintain
and periodically calibrate the Beacon 200 as described in
this manual.
Table 1: 72-2102-07 Beacon 200 Specifications
Description Specification
Input Power
115/220V ~ ±10%, 50/60Hz, 0.5/0.3A
1
or
24 V +10% -8%, 0.6A
Construction (housing) Fiberglass/polyester with lexan window (NEMA 4X)
Controller Dimensions 21.0 in. H x 8.5 in. W x 7.00 in. D
(533 mm H x 216 mm W x 178 mm D)
Weight 20 lbs.
Environmental Conditions • -20°C to 50°C (-4°F to 122°F) max. ambient
• Maximum humidity of 80% relative
Relays • Relay contacts rated for 10A @ 115/220V~ resistive or10A @ 30V
resistive
• SPDT Form C
User Controls • Reset switch
• Program buttons: ESCAPE, UP/YES, DOWN/NO, and ENTER
Detection Range 0 to 100 PPM (parts per million) H
2
S
Alarm 1 Setpoint
10 ppm
2
Alarm 2 Setpoint
50 ppm
2
Response Time 90% in 30 seconds
Accuracy ± 5% of reading or ± 2 ppm H
2
S (whichever is greater)
*
1
The AC voltage input is factory set. The standard input is 115 V~.
*
2
The alarm setpoints shown are factory settings but they can be changed in the Channel Control and Setup
Program.
