10
9
8
7
6
5
4
3
2
1
NOT USED
NOT USED
E N GI NE S HU T DOW N S OL . (GN D)
E NGI NE S HU T D OW N S OL. (+ 12V )
OI L P RE S . S W I T C H
OI L P RE S . GA UGE
E N GI NE T EMP S W I T CH
ENGINE T EMP GAGE
+ 12 V OLT S
T A CH S IGNA L
Deutz 2011 Engine Wiring
LUBE OIL PRESS
SOLENOID
SHUTDOWN
LUBE OIL TEMP
G
P
WK
WK
G
BATTERY
+
6 RED
DEUTZ ALTERNATOR
D+
B+
W
STARTER MOTOR
M
31
30 50
1
2
MINUS TORQUE
START SOLENOID
(OPTIONAL ON TURBOS)
LDA SOLENOID
Facing Fr ont of Count er plug
O I L P S I S W I T C H ( W K )
6 5
O I L T E M P S W I T C H (W K )
A L T E R N A T O R ( D + )
2
1
4
3
2011 10-PIN PLUG
P l u g # 2 S T O P S O L E N O I D ( - )
LDA ( 50+) Optional
8 7
10
9
O I L P S I S E N D E R ( G )
O I L T E M P S E N D E R (G )
A L T E R N A T O R ( W )
STOP SOLENOI D ( +) Plug#1
M I N U S T O R Q U E S O L E N O I D ( 5 0 + )
AMP 1 0 PI N CONNE CT OR
ON E NGI NE
