Installation Instructions
Warning
Preparation for Installation
Surroundings
Keep the hood away from too many doors and windows, so as to avoid air convection affecting the efficiency.
Tools
The hood will be installed with the following tools: 1). an impact drill (with drill bit); 2). a wrench;
3). a screwdriver; and 4). a ruler.
Body Size
372
504（524)
Check the items in the box
2
368
895
652( 597）
Figure 2
CXW- 200-830 2
The hood is for daily household use. Please do not operate it in special circumstances (e.g. outdoor), nor
use it to discharge hazardous or explosive substances or gases. Before installation, the product shall be placed
in a dry and ventilated place without corrosive and harmful gases.
The marked sizes are for reference only. Size in the brackets is specific to A809 hood. (Unit: mm)
Note: There are 2 oil cups provided, one as spare oil cup and the other to be installed on the hood. When
using the hood, install the cup on the filter mesh.
Packing List
No.
Name
Quantity
1
12
11
6
5
4
3
2
Hood
Plastic expansion pipe
Operating Instructions
Envelope
1 piece
4 pieces
1 piece
1 piece
Check valve
1 set
ST4×18 self-tapping screw
10 pieces
Φ175 (OD) aluminum exhaust
pipe
13
14
ST4.8×50 wood screw
4 pieces
10
Hitching foot stopper
1 piece
M6 metal expansion pipe
1 pair
7
Oil cup
2 pieces
15
Hitching foot
1 piece
8
Φ175 (OD) exhaust pipe joint
9
Exhaust pipe tape
Fixed bar for exhaust pipe
1 set
吸油烟机
Range Hood
1. Flue gases shall not be discharged to the hot flue, which is exclusively used for discharging the combustion gas or
other fuel fumes.
2. Note that when installing the metal expansion pipe, the pipe shall match perfectly with the hole in size.
Overlarge hole is prohibited, as it will result in loose pipe and accidental drops.
3. If the hood is used together with a cooking hob burning gas or other fuels, the room must be well ventilated.
4. Flue diameter smaller than that of the exhaust pipe will affect the hood efficiency. So will overlong exhaust pipe.
5. Regulations concerning the discharge of air have to be fulfilled.
No.
Name
Quantity
A818
To Next Page
