Figure 21 Figure 22
7
Maintenance
There is a fire risk if cleaning is not carried out in accordance with the instructions.
CXW- 200-830 2
Note: Cleaning and maintenance must be done when the power is disconnected. Keep the electrical components
(e.g. motors, switches and connectors) away from water to avoid accidents.
Light Removal
Figure 24Figure 23
Filter Mesh Removal
Figure 26Figure 25
Note: When installing the filter mesh, put the side with screw holes inward.
吸油烟机
Range Hood
The hood shall be cleaned and maintained regularly depending on the surroundings, so as to keep its
cleanness & efficiency and extend its service life.
We recommend to:
●Clean the exhaust fume collecting hood and range hood body after each cooking.
●To ensure smooth discharge of fumes, the filter shall be cleaned regularly with warm water and detergent
according to actual situations. Be careful to avoid damage.
●Suitably wipe it with a wet cloth soaked in mild
● Don' t rinse with water to avoid accidents.
●
sharp in the gap between the light cover and hood.
Insert a small flathead screwdriver or something
●
from the hood. Pull out the connector to replace
the spotlight.
Raise it outward forcibly to remove the spotlight
● Align the Phillips screwdriver wit the screw hole
and raise it upward forcibly meanwhile rotating
it counter-clockwise about 120° , so as to
remove the screw out of the cross slot of the
exhaust fume collecting hood.
● Hold the two screws on the filter mesh and pull
it down to detach the two prongs inside from the
exhaust fume collecting hood. Then pull the
filter out in the arrow direction to remove it.
A818
A818
