9
Electrical Diagram
General Troubleshooting
Warning
Cause
Failure
No
1
2
3
4
5
吸油烟机
Range Hood
Spotlight
Motor
Capacitance 500VAC 6μF
Ground terminal
Power plug
Strong extraction switch
Medium extraction switch
Weak extraction switch
Stir-frying switch
Lighting switch
LED
Yellow/Green
Yellow/Green E
Blue
Red
Brown
Orange
Grey
Black
White
Blue
Brown
Blue
Blue
Red
Yellow
Red
Connection box
Control circuit
Function circuit
L
D
220V~
XP
K5
K4
K3
K2
K1
No response after pressing any button
(e.g. the impeller does not rotate,
light is "OFF")
Light "OFF" after pressing the light button
Induced current on the hood body that
paralyzes hands
Abnormal sound during impeller running
No oil in the oil cup after a period of time
The power is not connected
properly or there is power failure
The light is damaged or poorly
connected
The power outlet is not well
The impeller is loose and the
cap is not tightened
The body is tilt
1. Please unplug the
p o w e r c o r d w h e n
connecting the plug-ins
or replacing any part.
2. If the hood's power
cord is damaged, it must
be re placed by our
maintenance staff.
3. Keep the hood
away from fire to avoid
accidents.
For other failures, please contact the vendor, special service center or our service center directly.
Warning
There shall be adequate ventilation of the room when the range hood is used at the same time as appliances
burning gas or other fuels.
- Do not flambé under the range hood.
- This appliance is not intended for use by persons (including children) with reduced physical, sensory, or
mental capacities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with the appliance.
- If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
Accessible parts may become hot when used with cooking appliances.
The minimum distance between the supporting surface for the cooking vessels on the hob and the lowest
part of the range hood. When the range hood is located above a gas appliance, this distance shall be at least
65 cm. If the instructions for installation for the gas hob specify a greater distance, this has to be taken into
account.
-
-
