DMX protocol
1 2 3
Mode/channel
DMX
Value
Function
Type of
control
1 - 255 Time of colour wheel movement (0.1 sec. --- >25.5 sec.) proportional
* * 12
Static gobo time
0 Function is off step
1 - 255 Time of static gobo wheel movement (0.1 sec. --- >25.5 sec.) proportional
* * 13
Prism time
0 Function is off step
1-50 Time of prism movement (0.1 sec. --- > 5 sec.) proportional
1 - 255 Time of prism rotation (0.1 sec. --- >25.5 sec.) proportional
* * 14
Zoom time
0 Function is off step
1 - 255 Time of zoom movement (0.1 sec. --- >25.5 sec.) proportional
* * 15
Focus time
0 Function is off step
1 - 255 Time of zoom movement (0.1 sec. --- >25.5 sec.) proportional
10 7 16
Static gobo wheel
0-3 Open/hole step
Positioning
4-9 Gobo 1 step
10-15 Gobo 2 step
16-21 Gobo 3 step
22-27 Gobo 4 step
28-33 Gobo 5 step
34-39 Gobo 6 step
40-45 Gobo 7 step
46-51 Gobo 8 step
52-57 Gobo 9 step
58-63 Gobo 10 step
64-69 Beam reducer 1 step
70-75 Beam reducer 2 step
76-81 Beam reducer 3 step
82-87 Beam reducer 4 step
Shaking gobos from slow to fast
88-95 Gobo 1 proportional
96-103 Gobo 2 proportional
104-111 Gobo 3 proportional
112-119 Gobo 4 proportional
120-127 Gobo 5 proportional
128-135 Gobo 6 proportional
136-143 Gobo 7 proportional
144-151 Gobo 8 proportional
152-159 Gobo 9 proportional
160-167 Gobo 10 proportional
168-175 Beam reducer 1 proportional
176-183 Beam reducer 2 proportional
184-191 Beam reducer 3 proportional
192-199 Beam reducer 4 proportional
200-201 Open/hole step
202 - 221 Forwards gobo wheel rotation from fast to slow proportional
222 - 223 No rotation
224 - 243 Backwards gobo wheel rotation from slow to fast proportional
