DMX protocol
1 2 3
Mode/channel
DMX
Value
Function
Type of
control
244 - 249 Random gobo selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random gobo selection from fast to slow proportional
11 8 17
Rotating gobo wheel
In the range of 0-59 DMX the gobo selection speed is controlled
by the Effect Speed channel.
Index - set indexing on channel 12/9/17
0 Open/Hole (default) step
1-4 Hole (flat field) step
5-7 Gobo 1 step
8-10 Gobo 2 step
11-13 Gobo 3 step
14-16 Gobo 4 step
17-19 Gobo 5 step
20-22 Gobo 6 step
23-25 Gobo 7 step
26-28 Gobo 8 step
29-31 Gobo 9 step
Rotation - set rotation on channel 12/9/17
32-34 Gobo 1 step
35-37 Gobo 2 step
38-40 Gobo 3 step
41-43 Gobo 4 step
4-46 Gobo 5 step
47-49 Gobo 6 step
50-52 Gobo 7 step
53-55 Gobo 8 step
56-59 Gobo 9 step
Shaking gobos from slow to fast
Index - set indexing on channel 12/9/17
60-67 Gobo 1 proportional
68-75 Gobo 2 proportional
76-83 Gobo 3 proportional
84-91 Gobo 4 proportional
92-99 Gobo 5 proportional
100-107 Gobo 6 proportional
108-115 Gobo 7 proportional
116-123 Gobo 8 proportional
124-129 Gobo 9 proportional
Shaking gobos from slow to fast
Rotation - set rotation on channel 12/9/17
130-137 Gobo 1 proportional
138-145 Gobo 2 proportional
146-153 Gobo 3 proportional
154-161 Gobo 4 proportional
162-169 Gobo 5 proportional
170-177 Gobo 6 proportional
178-185 Gobo 7 proportional
186-193 Gobo 8 proportional
194-199 Gobo 9 proportional
