Robe ROBIN Pointe - Page 45

DMX protocol
1 2 3
Mode/channel
DMX
Value
Function
Type of
control
200 - 201 Open/hole step
202 - 221 Forwards gobo wheel rotation from fast to slow proportional
222 - 223 No rotation step
224 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Random gobo selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random gobo selection from fast to slow proportional
12 9 18
Rot. gobo indexing and rotation
Gobo indexing - set position on channel 11/8/16
0 - 255 Gobo indexing proportional
Gobo rotation - set position on channel 11/8/16
0 No rotation step
1 - 127 Forwards gobo rotation from fast to slow proportional
128 - 129 No rotation step
130 - 255 Backwards gobo rotation from slow to fast proportional
13 * 19
Rot. gobo indexing and rotation - fine
0-255 Fine indexing (rotation) proportional
14 10 20
Prism
0 - 19 Open position (hole) step
20 -49 6-facet linear rotating prism -indexing step
50 - 75 6-facet linear rotating prism- rotation step
76 - 105 8-facet circular rotating prism- Indexing step
106-127 8-facet circular rotating prism-rotation step
Prism/gobo macros
128 - 135 Macro 1 step
136 - 143 Macro 2 step
144 - 151 Macro 3 step
152 - 159 Macro 4 step
160 - 167 Macro 5 step
168 - 175 Macro 6 step
176 - 183 Macro 7 step
184 - 191 Macro 8 step
192 - 199 Macro 9 step
200 - 207 Macro 10 step
208 - 215 Macro 11 step
216 - 223 Macro 12 step
224 - 231 Macro 13 step
232 - 239 Macro 14 step
240 - 247 Macro 15 step
248 - 255 Macro 16 step
15 11 21
Prism rotation and indexing
Prism indexing - set position on channel 14/10/19
0 - 255 Prism indexing proportional
Prism rotation - set position on channel 14/10/19
0 No rotation step
1 - 127 Forwards prism rotation from fast to slow proportional
128 - 129 No rotation step
130 - 255 Backwards prism rotation from slow to fast proportional
16 12 22
Frost
0 Open step
