CUTTING
CUTTING PREPARATION
Adjust the angle attachment to
desired angle as needed (Fig. 4-A,B).
The angle attachment can be used
on left side of the table (Fig. 4).
WARNING Do not put your fingers
against the sharp edge of the blade
at any time.
STRAIGHT CUTTING
Insert material between the cutting
blade and the base, flush with the
angle attachment (Fig. 5) and hold
the material with foot then push
handle down to complete a cut.
WARNING Maintain control of the
handle. Do not allow handle to slam
back after making cut.
45º CUTTING
Swing the angle attachment to 45°.
Insert material between the cutting
blade and the base, against the
angle attachment (Fig. 5), then push
the handle down to complete a cut.
WARNING Maintain control of the
handle. Do not allow handle to slam
back after making cut.
WARNING Do not put your fingers
against the sharp edge of the blade
at any time.
FIGURE 4
FIGURE 5
