Robertshaw RS5110 Installation Manual

2
Thank you for purchasing a Robertshaw
®
thermostat. This manual will
describe how to install and test the Robertshaw single stage
thermostats RS4110, RS5110, RS6110, two stage RS4220, RS5220, RS6220,
and three stage* RS4320, RS6320 thermostats. For complete operation
instructions, refer to the Robertshaw User Manual.
Use the model number to identify your thermostat.
These thermostats have three main parts:
A. The backplate – mounts to the wall and has wire connections.
B. The body – snaps to the backplate and contains the electronics and
programming buttons.
C. The cover – snaps to the top of the body and swings up to give
access to the programming buttons.
Recycling Thermostat
If this thermostat is replacing a thermostat that contains mercury in a
sealed tube, do not place your old thermostat in the garbage. Contact
your local waste management authority for instructions regarding
proper disposal of the thermostat. If you have any questions, call
Robertshaw technical support at 1-800-445-8299.
R S X 1 1 0
4 = Non-Programmable
Value Series
5 = Programmable Value Series
with 5-2 Day Schedule
6 = Programmable Value Series
with 7 Day Schedule and
Copy Feature
Application
0 = Standard Thermostat
Number of Cooling Stages
Number of Heating Stages
* Three stages of heating available for heat pump applications only.

Robertshaw RS5110 Specifications

General

Brand	Robertshaw
Model	RS5110
Category	Thermostat
Language	English
