Robertshaw RS8210 Installation Manual

WIRING
8
C
O
B
E
Y
G
RH/R
W2
6 Connect Wires
Simply match wire labels.
If labels do not match letters on the thermostat, check “Alternate Wiring (Conventional
Systems)” on page 9 and connect to terminal as shown (see notes, below).
Screw
Insert wires and
tighten screws

Robertshaw RS8210 Specifications

General

Brand	Robertshaw
Model	RS8210
Category	Thermostat
Language	English
