DMX protocol

77-78

Filter 154 (Pale Rose)

step

79-80

Filter 157 (Pink)

step

81-82

Filter 143 (Pale Navy Blue)

step

83-84

Filter 162 (Bastard Amber)

step

85-86

Filter 164 (Flame Red)

step

87-88

Filter 165 (Daylight Blue)

step

89-90

Filter 169 (Lilac Tint)

step

91-92

Filter 170 (Deep Lavender)

step

93-94

Filter 172 (Lagoon Blue)

step

95-96

Filter 194 (Surprise Pink)

step

97-98

Filter 180 (Dark Lavender)

step

99-100

Filter 181 (Congo Blue)

step

101-102

Filter 197 (Alice Blue)

step

103-104

Filter 201 (Full C.T. Blue)

step

105-106

Filter 202 (Half C.T. Blue)

step

107-108

Filter 203 (Quarter C.T. Blue)

step

109-110

Filter 204 (Full C.T. Orange)

step

111-112

Filter 219 (Fluorescent Green)

step

113-114

Filter 206 (Quarter C.T. Orange)

step

115-116

Filter 247 (Filter Minus Green)

step

117-118

Filter 248 (Half Minus Green)

step

119-120

Filter 281 (Three Quarter C.T. Blue)

step

121-122

Filter 285 (Three Quarter C.T. Orange)

step

123-124

Filter 352 (Glacier Blue)

step

125-126

Filter 353 (Lighter Blue)

step

127-128

Filter 507 (Madge)

step

129-130

Filter 778 (Millennium Gold)

step

131-132

Filter 793 (Vanity Fair)

step

133-235

Raw DMX

proportional

236-245 Rainbow effect (with fade time) from slow-> fast proportional

246-255 Rainbow effect (without fade time) from slow-> fast proportional

* 8 8 8

Red/Cyan (8 bit)- all pixels***

0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional

* * 9 9

Red/Cyan (16bit)- all pixels***

0 - 255 Colour saturation control - fine (255=default) proportional

* 9 10 10

Green/Magenta (8 bit) - all pixels ***

0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional

* * 11 11

Green/Magenta (16bit) - all pixels***

0 - 255 Colour saturation control - fine (255=default) proportional

* 10 12 12

Blue/Yellow (8 bit) - all pixels ***

0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional

* * 13 13

Blue/ Yellow (16bit) -all pixels***

0 - 255 Colour saturation control - fine (255=default) proportional

* 11 14 14

White (8 bit) - all pixels

If RGBW mode is selected:

0-255 Colour saturation control - coarse 0-100% (255=default) proportional

If CMY mode is selected:

0 - 255 No function

* * 15 15

White (16 bit) - all pixels

0 - 255 Colour saturation control - fine (255=default) proportional
