DMX protocol
8 * * *
Red/Cyan (8 bit) - zone 1***
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
9 * * *
Red/Cyan (16bit)- zone 1***
0 - 255 Colour saturation control - fine (255=default) proportional
10 * * *
Green/Magenta (8 bit) - zone 1***
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
11 * * *
Green/Magenta (16bit)- zone 1***
0 - 255 Colour saturation control - fine (255=default) proportional
12 * * *
Blue/Yellow (8 bit) - zone 1***
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
13 * * *
Blue/Yellow (16bit)- zone 1***
0 - 255 Colour saturation control - fine (255=default) proportional
14 * * *
White (8 bit) - zone 1
If RGBW mode is selected:
0-255 Colour saturation control - coarse 0-100% (255=default) proportional
If CMY mode is selected:
0 - 255 No function
15 * * *
White (16 bit) - zone 1
0 - 255 Colour saturation control - fine (255=default) proportional
16 * * *
Red/Cyan (8 bit) - zone 2***
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
17 * * *
Red/Cyan (16bit)- zone 2***
0 - 255 Colour saturation control - fine (255=default) proportional
18 * * *
Green/Magenta (8 bit) - zone 2***
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
19 * * *
Green/Magenta (16bit)- zone 2***
0 - 255 Colour saturation control - fine (255=default) proportional
20 * * *
Blue/Yellow (8 bit) - zone 2***
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
21 * * *
Blue/Yellow (16bit)- zone 2***
0 - 255 Colour saturation control - fine (255=default) proportional
22 * * *
White (8 bit) - zone 2
If RGBW mode is selected:
0-255 Colour saturation control - coarse 0-100% (255=default) proportional
If CMY mode is selected:
0 - 255 No function
23 * * *
White (16 bit) - zone 2
0 - 255 Colour saturation control - fine (255=default) proportional
24 * * *
Red/Cyan (8 bit) - zone 3***
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
25 * * *
Red/Cyan (16bit)- zone 3***
0 - 255 Colour saturation control - fine (255=default) proportional
26 * * *
Green/Magenta (8 bit) - zone 3***
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
27 * * *
Green/Magenta (16bit)- zone 3***
0 - 255 Colour saturation control - fine (255=default) proportional
28 * * *
Blue/Yellow (8 bit) - zone 3***
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
29 * * *
Blue/Yellow (16bit)- zone 3***
0 - 255 Colour saturation control - fine (255=default) proportional
