DMX protocol
30 * * *
White (8 bit) - zone 3
If RGBW mode is selected:
0-255 Colour saturation control - coarse 0-100% (255=default) proportional
If CMY mode is selected:
0 - 255 No function
31 * * *
White (16 bit) - zone 3
0 - 255 Colour saturation control - fine (255=default) proportional
32 12 16 16
CTC
If function "White Point 8000K" is ON
0-255
Col. temperature correction from 8000K to 2700K -for whites only
proportional
(0=8000K, 64=5600K, 128=4200K, 192=3200K, 255=2700K)
To get colour temperatures stated above, RGBW channels have to
be set at the same value (e.g. 255DMX) or RGB=0 and White
channel > 0 DMX (0=default)
(To activate Tungsten effect at 2700K and 3200K , set DMX value at
"Power/Special functions" channel)
If function "White Point 8000K" is OFF
0-255 Colour temperature correction from cool col. to warm colours proportional
33 13 17 17
Colour Mix control
The channel defines relation between color channels
IF Flower effect is active, its colour channels always have priority!
Global = Global Colours (RGBW, Virtual Colour Wheel)
Pixel = Pixel Colours (RGB individual pixels or Kling-Net)
0-9 Global colours (Global has priority)
10-19 Maximum mode (highest values have priority) step
20-29 Minimum mode (lowest values have priority) step
30-39 Multiply mode (multiply Global and Pixel) step
40-49 Addition mode (Global + Pixel) /45=default/ step
50-59 Subtraction mode (Global – Pixel) step
60-69 Inverted Subtraction mode (Pixel – Global) step
70-79 Coloured background step
80-127 Raw DMX proportional
128 Global colours only (Global has priority) step
129-254 Crossfade (crossfade between Global and Pixel) proportional
255 Pixel colours (Pixel has priority) step
34 14 18 18
Pixel effects
0-2 No function (0=default)
3-4 Effect 1 step
5-6 Effect 2 step
: : :
181-182 Effect 90 step
183-255 Raw DMX proportional
35 15 19 19
Pixel effects speed
0-127 Speed from from min. to max. (0=default) proportional
128-255 Speed from max. to min. (opposite direction) proportional
36 16 20 20
Pixel effects fade
0 Without fade time (0=default) step
1-255 Fade time from min. to max. proportional
37 17 21 21
Flower Effect
0 Open position-without Flower Effect (0=default) step
