DMX protocol
1 - 127 Flower Effect forwards rotation from fast to slow proportional
128 Flower Effect -without rotation step
129-255 Backwards rotation from slow to fast proportional
38 18 22 22
Flower Effect - Red (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
39 19 23 23
Flower Effect - Green (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
40 20 24 24
Flower effect - Blue (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
41 21 25 25
Flower Effect - White (8 bit)
0-255 Colour saturation control - coarse 0-100% (255=default) proportional
42 22 26 26
Flower Effect - colour macros
(Flower Effect channel has to be set > 0 DMX)
step
0
Open position - without macros (0=default)
(Flower effect colour macros have priority to RGBW colours/Virtual colour
wheel,Flower effect colours )
1-2
Flower Effect colour macro 1
step
3-4
Flower Effect colour macro 2
step
5-6
Flower Effect colour macro 3
step
:
119-120
Flower Effect colour macro 60
step
121-255
Raw DMX
proportional
43 23 27 27
Flower Effect - Shutter/ strobe
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open step
44 24 28 28
Flower Effect - Dimmer intensity (8 bit)
0 - 255 Dimmer intensity from 0% to 100% (0=default) proportional
45 25 29 29
0-255 Zoom from max. to min.beam angle (128=default) proportional
46 * 30 30
0-255 Fine zooming (0=default) proportional
47 26 31 31
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open step
48 27 32 32
0 - 255 Dimmer intensity from 0% to 100% (0=default) proportional
