DMX protocol
5 6 7 8 9 10
Mode/channel
DMX
Value
Function
Type of
control
0-255 Colour saturation control - coarse 0-100% (255=default) proportional
If CMY mode is selected:
0 - 255 No function
* 15 15 15 15 15
Background - White (16 bit) - all pixels
0 - 255 Colour saturation control - fine (255=default) proportional
12 16 16 16 16 16
If function "White Point 8000K" is ON
0-255 Col. temperature correction from 8000K to 2700K -for whites only proportional
(0=8000K, 64=5600K, 128=4200K, 192=3200K, 255=2700K)
To get colour temperatures stated above, RGBW channels have to
be set at the same value (e.g. 255DMX) or RGB=0 and White
channel > 0 DMX (0=default)
(To activate Tungsten effect at 2700K and 3200K , set DMX value at
"Power/Special functions" channel)
If function "White Point 8000K" is OFF
0-255 Colour temperature correction from cool col. to warm colour proportional
13 17 17 17 17 17
Background - Shutter/ strobe
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe effect from slow to fast proportional
224 - 255 Shutter open step
14 18 18 18 18 18
Background - Dimmer intensity (8 bit)
0 - 255 Dimmer intensity from 0% to 100% (255=default) proportional
* 19 19 19 19 19
Background Dimmer intensity - fine (16 bit)
0 - 255 Fine dimming (255=default) proportional
15 20 20 20 20 20
0-2 All pixels (0=default)
3-4 Ring 1 (Middle pixel) step
5-6 Ring 2 step
7-8 Ring 3 step
9-10 Ring 1+ Ring 2 step
11-12 Ring 1+ Ring 3 step
13-14 Ring 2 + Ring 3 step
15-16 Sector 1 step
17-18 Sector 2 step
19-20 Sector 3 step
21-22 Sector 4 step
23-24 Sector 5 step
25-26 Sector 6 step
27-28 Sector 1+4 step
29-30 Sector 1+4+Ring 1 step
31-32 Sector 2+5 step
33-34 Sector 2+5+Ring 1 step
35-36 Sector 3+6 step
