DMX protocol
5 6 7 8 9 10
Mode/channel
DMX
Value
Function
Type of
control
37-38 Sector 3+6+Ring 1 step
39-40 Sector 1+3+5 step
41-42 Sector 1+3+5+Ring 1 step
43-44 Sector 2+4+6 step
45-46 Sector 2+4+6+Ring 1 step
47-48 Sector 1+2+3 step
49-50 Sector 2+3+4 step
51-52 Sector 3+4+5 step
53-54 Sector 4+5+6 step
55-56 Sector 5+6+1 step
57-58 sector 6+1+2 step
59-255 Raw DMX proportional
16 21 21 21 21 21
Colour Mix control
The channel defines relation between color channels
IF Flower effect is active, its colour channels always have priority!
Global = Global Colours (Background RGBW, Background Virtual
Colour Wheel, Background CTC)
Pixel = Pixel Colours (RGB individual pixels or Kling-Net)
0-9 Global colours (Global has priority)
10-19 Maximum mode (highest values have priority) step
20-29 Minimum mode (lowest values have priority) step
30-39 Multiply mode (multiply Global and Pixel) step
40-49 Addition mode (Global + Pixel) /45=default/ step
50-59 Subtraction mode (Global – Pixel) step
60-69 Inverted Subtraction mode (Pixel – Global) step
70-79 Coloured background step
80-127 Raw DMX proportional
128 Global colours only (Global has priority) step
129-254 Crossfade (crossfade between Global and Pixel) proportional
255 Pixel colours (Pixel has priority) step
17 22 22 22 22 22
Flower Effect
0 Open position-without Flower Effect (0=default) step
1 - 127 Flower Effect forwards rotation from fast to slow proportional
128 Flower Effect -without rotation step
129-255 Backwards rotation from slow to fast proportional
18 23 23 23 23 23
Flower Effect - Red/Cyan (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
19 24 24 24 24 24
Flower Effect - Green/Magenta (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
20 25 25 25 25 25
Flower effect - Blue/Yellow (8 bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
21 26 26 26 26 26
Flower Effect - White (8 bit)
0-255 Colour saturation control - coarse 0-100% (255=default) proportional
22 27 27 27 27 27
Flower Effect - colour macros
(Flower Effect channel has to be set > 0 DMX) step
0 Open position - without macros (0=default)
(Flower effect colour macros have priority to RGBW colours/Virtual colour
wheel,Flower effect colours, channels Flower effect-Shutter/strobe and
Flower effect-dimmer has to be open )
