DMX protocol
5 6 7 8 9 10
Mode/channel
DMX
Value
Function
Type of
control
1-2 Flower Effect colour macro 1 step
3-4 Flower Effect colour macro 2 step
5-6 Flower Effect colour macro 3 step
:
119-120 Flower Effect colour macro 60 step
121-255 Raw DMX proportional
23 28 28 28 28 28
Flower Effect - Shutter/ strobe
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open step
24 29 29 29 29 29
Flower Effect - Dimmer intensity (8 bit)
0 - 255 Dimmer intensity from 0% to 100% (255=default) proportional
25 30 30 30 30 30
0-255 Zoom from max. to min.beam angle (128=default) proportional
* 31 31 31 31 31
0-255 Fine zooming (0=default) proportional
* 32 * * 32 32
0-2 No pattern (0=default)
3-4 Pattern 1 step
5-6 Pattern 2 step
7-8 Pattern 3 step
9-10 Pattern 4 step
11-12 Pattern 5 step
13-14 Pattern 6 step
15-16 Pattern 7 step
17-18 Pattern 8 step
19-20 Pattern 9 step
21-22 Pattern 10 step
23-24 Pattern 11 step
25-255 RAW DMX proportional
* 33 * * 33 33
0-2 Variant 1 (0=default) step
3-4 Variant 2 step
5-6 Variant 3 step
7-8 Variant 4 step
9-10 Variant 5 step
11-12 Variant 6 step
13-14 Variant 7 step
15-16 Variant 8 step
17-18 Variant 9 step
19-20 Variant 10 step
21-22 Variant 11 step
