DMX protocol
5 6 7 8 9 10
Mode/channel
DMX
Value
Function
Type of
control
23-255 Raw DMX proportional
* 34 * * 34 34
Pattern - Rotation
0 No rotation (0=default) step
1-127 Pattern indexing proportional
128-190 Forwards rotation from fast to slow proportional
191-192 Pause - without rotation step
193-255 Backwards rotation from slow to fast proportional
* 35 * * 35 35
Pattern - Fade
0 Snap (0=default) step
1-255 Fade from min. to max. proportional
* 36 * * 36 36
Pattern -Transition
0 No fade (0=default) step
1 100ms step
:
255 4 sec step
* 37 * * 37 37
Pattern - Crossfade
0 Background step
1-255 Crossfade between Background and Pattern 0-100% (255=default) proportional
* 38 * * 38 38
Pattern - Red (8-bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
* 39 * * 39 39
Pattern - Green (8-bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
* 40 * * 40 40
Pattern - Blue (8-bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
* 41 * * 41 41
Pattern - White (8-bit)
0 - 255 Colour saturation control - coarse 0-100% (255=default) proportional
* 42 * * 42 42
Pattern - Colour macro
0-2 No macro (0=default) step
Macros 1-15 allow control of colour change speed from min. to max.
3-8 Macro 1 proportional
9-14 Macro 2 proportional
15-20 Macro 3 proportional
21-26 Macro 4 proportional
27-32 Macro 5 proportional
33-38 Macro 6 proportional
39-44 Macro 7 proportional
45-50 Macro 8 proportional
51-56 Macro 9 proportional
57-62 Macro 10 proportional
63-68 Macro 11 proportional
69-74 Macro 12 proportional
75-80 Macro 13 proportional
81-86 Macro 14 proportional
87-92 Macro 15 proportional
93-98 Macro 16 step
99-104 Macro 17 step
105-110 Macro 18 step
111-255 Raw DMX proportional
