DMX protocol
5 6 7 8 9 10
Mode/channel
DMX
Value
Function
Type of
control
* 43 * * 43 43
Pattern - Shutter/ strobe
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe effect from slow to fast proportional
224 - 255 Shutter open step
* 44 * * 44 44
Pattern - Dimmer intensity (8 bit)
0 - 255 Dimmer intensity from 0% to 100% (255=default) proportional
26 45 32 32 45 45
Master Shutter/ strobe
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe effect from slow to fast proportional
224 - 255 Shutter open step
27 46 33 33 46 46
Master Dimmer intensity (8 bit)
0 - 255 Dimmer intensity from 0% to 100% (0=default) proportional
* 47 34 34 47 47
Master Dimmer intensity - fine (16 bit)
0 - 255 Fine dimming (0=default) proportional
* * 35 35 48 48
Red pixel 1
0-255 Red LED saturation control 0-100% (0=default) proportional
* * 36 36 49 49
Green pixel 1
0-255 Green LED saturation control 0-100% (0=default) proportional
* * 37 37 50 50
Blue pixel 1
0-255 Blue LED saturation control 0-100% (0=default) proportional
* * * 38 * 51
White pixel 1
0-255 White LED saturation control 0-100% (0=default) proportional
:
* * 89 104 102 120
Red pixel 19
0-255 Red LED saturation control 0-100% (0=default) proportional
* * 90 105 103 121
Green pixel 19
0-255 Green LED saturation control 0-100% (0=default) proportional
* * 91 106 104 122
Blue pixel 19
0-255 Blue LED saturation control 0-100% (0=default) proportional
* * * 110 * 123
White pixel 19
0-255 White LED saturation control 0-100% (0=default) proportional
* function is active only 10 seconds after switching the fixture on
** In the Tungsten effect simulation the Dimmer channel imitates behaviour of the halogen lamp during dimming
*** Select RGB or CMY mixing mode on channel "Power/Special functions"
