Roboguard
Mounting Brackets
Roboguard installation using a mounting bracket is highly
recommended.
The bracket can be mounted to any surface and allows the installer to
swivel the Roboguard and aim the beams in the required direction.
This is particularly usefull when setting up in walk-test mode as you
can also aim the beams between obstacles or down a narrow alleyway.
The bracket has top and bottom slots to allow you to set the unit
vertical if the mounting surface is not completely vertical.
Mount the stainless steel bracket to a solid
vertical surface
Select a set of locators according to the need
per site. i.e. If you are detecting down a hill,
choose the lower locators for maximum
angle.
