Roboguard 34
UNIVERSAL TRANSMITTER - uTx
1. The uTx can be wired to a receiver and
configured to be a Repeater Station
for increased radio distance.
2. The Universal Transmitter (uTx) has
four zone inputs that can be wired to
any device, such as an Electric Fence,
indoor passive, panic button, reed
switch etc. This will allow these devices
to communicate with any Roboguard
receiver. The uTx can mimic either
Roboguards or (not both) Remote
Transmitter functions; these unique
codes can be programmed into an HQ,
Keypad or a Universal Receiver
(Roboguard receiver/decoder panels).
3. The input zone sends an intruder signal as soon as the input state is
changed (N/C to N/O or vice versa) and will stop sending the
supervisory Auto Test signal if it remains in the altered state;
thereby monitoring functionality of the devices wired to it. (Auto
test signals apply to Roboguard Code only)
Switch 1 - ON (Default). In this mode the unit will function as a
repeater station.
Switch 2, 3, and 4 will implement the following delay time between
receiving and transmitting a signal.
Delay Switch 2 Switch 3 Switch 4
2.4 SEC OFF OFF OFF
2.8 SEC OFF OFF ON
2.8 SEC OFF ON OFF
4 SEC OFF ON ON
4.8 SEC ON OFF OFF
5 SEC ON ON OFF
6.5 SEC ON ON ON
