24
4.6 Placement and connection of the Base Station
o Place the Base Station on the Perimeter Wire as shown
in the gure to the right.
o Align the center of the Base Station on the wire.
o Attach the Perimeter Wire connector to the Base Station
Head.
o After the Base Station has been positioned, insert 2
stakes into the Base Station holes as shown in the gure
to the right. Only after the Base Station position has
been tested during the One-Time Setup process (see
Section 5.2), you will be able to insert the remaining two
stakes.
4.7 Connecting the Power Box
In order to nd a proper location for the Power Box, please refer to Section 3.3.
For the Power Box installation instructions please refer to Section 4.1.2.
Laying and Fastening Extension Cable
Safety – Avoid injury!
The Extension Cable from the Power Box to the Base Station should
be securely fastened to the ground! It should never present a tripping
hazard.
The Extension Cable should cross ONLY over soft surfaces. It should
not cross over hard surfaces (e.g. Sidewalk, driveway) where it cannot
be securely fastened.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Robomow RC304 and is the answer not in the manual?

Robomow RC304 Specifications

General IconGeneral
Cutting Width28 cm
Cutting Height15-60 mm
Battery TypeLithium-Ion
Mower TypeRobotic
Rain SensorYes
Smartphone AppYes
Boundary Wire RequiredYes
Warranty2 years
Mowing Area400 m²
Slope Capability20°
Programming OptionsYes
Power200 W
Working Time60 minutes
