Robomow RC304u Operation And Safety Manual

48
Problem
Encountered
Probable Cause/Event Correcve Acons
Mower does not
dock properly
and sometimes
misses the Base
Station contacts
- Height differences between the lawn and
the Base Station surface.
- FillsomegroundtoattenthelawntotheBase
Station to allow smooth entrance.
- The wire underneath the Base Station is
not tight and placed in the middle of the
Station.
- ConrmthewireunderneaththeBaseStation
is straight, tight, and centered below the Base
Station.
- The Base Station is set up on a side
slope.
- Move the Base Station to a relatively level
ground.
- The Base Station is placed too close to
the corner of the lawn
- Move the Base Station so it is not within 3
meters after a corner.
Uneven mowing
results
- The time between operations is too long
because of long inactive time windows.
- Minimize the Inactive Time windows to allow
Robomow to complete the Mowing Cycle faster
and to achieve even mowing results.
- Grass is growing very fast.
- If it is during a fast growing season – change
the Mowing Frequency (refer to Section 6.4.2 –
P001).
- The shape of the lawn is complicated
(Narrow Passages, obstacle and islands).
- In a complicated lawn more time is required for
the mower to achieve better mowing results.
- Increase the mowing hours percentage (refer to
Section 6.4.1.2).
- The set area is smaller than the actual
lawn size.
- Increase the zone area (refer to Section 6.4.1.4)
Robomow
operates during
Inactive Time.
- Wrong clock time is set in the mower.
- Verify that the time on the mower is set correctly.
- Set the time (refer to Section 6.4.1.1).
- Reset the Inactive Time (refer to Section
6.4.1.3).
Robomow
operates during
rain
- Rain Sensor is disabled or its sensitivity
is set too low
- Enable the Rain Sensor and adjust its sensitivity
if required (refer to Section 6.4.2 – P007/p008)
- The Islands feature is set to On. In this
case the mower is searching for the base
by moving around the lawn. This special
search method takes more time, and
may create an impression that the mower
is still mowing, while in fact it is already
searching for the Base Station.
- No special action is required. For more
information about the Islands On/Off feature
refer to Section 6.4.2 – P002)
Cut wire indicator
isashingon
Power Box
- The Extension Cable is disconnected or
damaged between Power Box and the
Base Station.
- ConrmtheExtensionCableispluggedinand
wireleadsarermlyattached.
- Perimeter Wire is cut.
- Walk along Perimeter Wire.
- Look for cuts or breaks in the wire.
- Repair with Robomow wire splice connectors.
- Scan the code and
watch the video
demonstrating the
Corrective Actions of
the “Perimeter Wire
is cut”.
The poor
connection
indicator is
ashingon
Power Box
- Poor connections
- Check and repair all loose, poor, or corroded
connections.
- Twisted cables or a screw terminal which
is insulated with insulation tape is not a
satisfactory splice.
- Soil moisture causes the conductors to
oxidize.
- Use the connectors supplied in the box. They
are waterproof and give a reliable electrical
connection.

Robomow RC304u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	500 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	0.83 h
Battery voltage	26 V
Battery capacity	2.4 Ah
Battery life (max)	50 min
Battery technology	Lithium
Power consumption per month (max)	11 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
