Robomow RC304u Operation And Safety Manual

49
EN
9.4.1 Description of No-Depart Codes
Code Descripon Correcve Acon
00
None. Automatic departure is working properly None. Wait for the end of current charging cycle
01
Mower’s battery is not yet in the required state
forautomatic departure
None. Wait for the end of current charging cycle.
May take longer than usual
02
Inactive Time is activated. No automatic
departure during Inactive Time
None. Validate Inactive Time settings (see
Section 6.4.1.3)
03
Mowing cycle is completed. Waiting for the next
scheduled operation
None
04
Humid conditions or rain were detected during
last 30 minutes.
- None. If the rain has stopped, wait for another
30 minutes at least
- If there was no any raining at all, consider
adjusting rain sensor’s sensitivity (see P008 in
Section 6.4.2) or call Robomow Hotline
05
The mower is switched off Switch on the Safety Switch
07
User response (interaction) is required in order to
continue current operation
Acknowledge the error message
08
Multiple consecutive mowing operations were
shorter than expected. Usually accompanied by
U018 (“Operation time is shorter than expected”)
- Inspect mower’s blade and drive wheels.
- Battery run-time may be too short.
09
One-Time setup is running
One-Time setup should be completed before the
automatic operation can start
11
Automatic operation is disabled by menu P021
(see Section 6.4.2)
Enable automatic operation through menu p021
12
Automatic operation is put on pause bythe Power
Box
Enable automatic operation via the Power Box.
13
All week days are set as inactive days
Validate Inactive Time settings (see Section
6.4.1.3)
14
The mower is being charged directly by the
Power Box (via the DC connector)
Disconnect the DC cable from the mower. Put
the mower in the Base Station.
15
Battery cells are being balanced in special
charging mode
None. Wait for the end of current charging cycle.
May take longer than usual.
16
The mower is in the Base Station, but there is no
charging voltage supply
- Inspect Power Box’s connection to the Base
Station
- Conrmthatnothingisblockingthecharging
pins
17
Low ambient temperature
None. The mower will automatically depart
when it gets warmer.
18
Sub-Zone entry problem. The mower was unable
to enter one of the Sub-Zones
Refer to U090-U093 in Section 9.3

Robomow RC304u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	500 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	0.83 h
Battery voltage	26 V
Battery capacity	2.4 Ah
Battery life (max)	50 min
Battery technology	Lithium
Power consumption per month (max)	11 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
