Roborock Dyad Pro Combo - Cleaning the Charging Dock Tray; Cleaning the Main Unit and Dustbin Combo Unit; Cleaning the Multi-Surface Brush; Cleaning the Motorized Mini-Brush

11
Grasp the side handles of the tray and
pull upward.
Rinse the tray with water and reinstall it
in place after drying.
E4
Cleaning the Charging
Dock Tray
E4-1—
E4-2—
E4-3—
Note: Only remove and wash the tray. Do
not wash any other parts of the charging
dock.
E5
Cleaning the Main Unit and
Dustbin Combo Unit
E6
Cleaning the Multi-Surface
Brush
Note: Use the maintenance brush carefully to avoid injury.
Do not wash the dustbin to avoid
damaging the electrical parts inside.
To discard the dust, press the dustbin
release button and remove the dustbin.
Turn the brush head over with the
bottom facing you. Look for debris,
including hair and fibers on the head or
in the bearings.
Cut off any hair entangled on the
roller and remove any debris using the
provided maintenance brush.
Remove the filter.
Grab the handle and lift out the cyclone
parts.
Discard the dust inside and install the
cyclone parts and filter back into the
dustbin.
E5-1—
E6-1—
E6-2—
E5-2—
E5-3—
E5-4—
E5-5—
E7
Cleaning the Motorized
Mini-Brush
Note: Use the maintenance brush carefully to avoid injury.
Hold the brush so the lock on the
side is facing you, and turn the lock
counterclockwise.
After removing the locking mechanism,
remove the roller.
Clean the roller with the maintenance
brush provided and then wash the roller.
Place the roller vertically and dry it for at
least 24 hours for it to dry thoroughly.
E7-1—
E7-2—
E7-3—
E7-4—
Basic Parameters
Main Unit
Model H1C1A
Rated Input 25.75V
1A
Battery
21.6 V/4000 mAh (TYP)
Lithium-ion battery
Dock Charger
Model
MDS01LRR or
MDS02LRR
Rated Input
Voltage
120V~
Rated
Frequency
60Hz
Rated Input 1A
Rated Output 25.75V
1A
Battery
21.6 V/4000 mAh (TYP)
Lithium-ion battery
