Roborock S6 Pure - Installation; Using the Robot

10
Product Introduction Installation
Mopping module Using the robot
1. Place the charging dock against the wall on a flat surface
and plug it into the mains power.
Charging dock
Water tank cover
Filter
Water tank
Mop cloth attachment slot
Flow control
Water tank latch
Water tank latch
Mop cloth
Attachment area
Charging
dock power
indicator
Power socket
Charging
points
Locator
beacon
Charging
points
More than 0.5m (1.6)
More than 0.5m (1.6)
More than 1.5m (4.9)
Note:
• The charging dock should have more than 0.5m (1.6) of clearance on each side,
and more than 1.5m (4.9) in the front.
• If the power cable is vertical to the ground, it may be caught by the robot, causing
the charging dock to be disconnected.
• The charging dock indicator is on when the charging dock is electrified, and o
when the robot is charging.
