Roborock S6 Pure User Manual

18
Instructions for Use Routine maintenance
Charging Dock
The charging dock should be plugged in and placed against
a wall on level ground, with more than 0.5m (1.6) of
clearance on each side, and more than 1.5m (4.9) in front.
For the best experience when using the mobile app, place
the charging dock in an area with strong WiFi coverage.
Note:
Do not place the charging dock in direct sunlight or block the locator beacon;
otherwise, the robot may not be able to return to the charging dock.
Locator beacon
More than
0.5m (1.6)
More than
0.5m (1.6)
More than
1.5m (4.9)
Main brush
*Clean weekly
1. Turn the robot over then unlatch and remove the main
brush cover.
2. Take out the main brush, remove and clean its bearings.
3. Remove the main brush cap, rotating in the unlock
direction.
4. Use the supplied main brush cleaning tool to remove any
entangled hair.
5. Re-install the cap and bearings following the lock
direction.
6. Re-insert the main brush and secure the brush cover.
Lock direction
Unlock direction
Main brush cover
Latch
Main brush
Main brush cap
Main
brush bearing
Alignment
mark
Note:
Main brush replacement every 6-12 months is recommended.

Roborock S6 Pure Specifications

General

Suction Power	2000 Pa
Battery Capacity	5200 mAh
Dustbin Capacity	460 ml
Water Tank Capacity	180 ml
Navigation	LDS Laser Navigation
Runtime	Up to 150 minutes
Virtual Barriers	Yes
Multi-Level Mapping	Yes
Scheduled Cleaning	Yes
Charging Time	Approximately 6 hours
Weight	3.2 kg
Connectivity	Wi-Fi
Compatible Floor Types	Hardwood, Tile, Carpet
Voice Control	Yes
Dimensions	350 x 350 x 96.5 mm (13.8 x 13.8 x 3.8 inches)
