Robot Coupe MP 450 Ultra - Assembling & Dismantling; Blade & Whisk Component Attachment

8
• WHISK FUNCTION
You can also hold the
appliance by the handle
with one hand, leaving
the other hand free to
hold the bowl, if neces-
sary.
While you process the
preparation, we recom-
mend that you move the
whisks around in the
bowl, in order to ensure
that the mixture is comple-
tely homogeneous.
We strongly advise you to
keep the whisks from
touching the sides of the
bowl.
For maximum efficiency,
at least one-fifth of the
whisk length should be
immersed. We also stron-
gly advise you to start the
processing at a low
speed.
Handle conveniently loca-
ted on the mixing tool for
a better grip.
TURN TO
ATTACH BELL
- Check that the machine is not plugged in.
- Align the flat side of the conical part of the
tube with catch on the inside of the bell.
- Insert the conical part into the bell. With the
washer touching the tube seal , turn the bell in
the direction of the arrow (see above figure) to
lock the bell lug and tube lug together
moderately tightly.
Removing the bell from the foot
(valid for all models)
- Check that the machine is not plugged in.
- Turn the bell in the direction of arrow (see next
figure) to separate the bell lug from the tube
lug . Remove the bell.
F
E
1
F
E
D
C
B
A
TURN TO
REMOVE BELL
ASSEMBLING
& DISMANTLING
• BLADE FUNCTION
Attaching the bell to the tube (valid for all models)
Attaching the tube to the motor unit.
(MP 350 Combi Ultra, MP 450 Combi Ultra,
MP 800 Turbo)
- Check that the appliance is not plugged in.
- Align the flat side of the conical part of the
tube with catch into the aluminium casing.
- Insert the whole of the conical part of the tube
into the aluminium casing.
- Turn the tube in the direction of the arrow (see
figure) until it is locked into place moderately
tightly.
C
B
A
